Waterproof Dc Dc Charger Wholesale - SKYFAVOR
Product details of the waterproof dc dc charger
Quick Overview
SKYFAVOR waterproof dc dc charger is assured with an invincible quality. In order to conform to the fashion of waterproof dc dc charger industry, our products are developed consistuted by the leading technology. The product is extremely suited for a variety of applications.
Product Description
Compared with other same kind of products, waterproof dc dc charger produced by Skyfavor has the following advantages and features.
|
DOITWELLSmart Automatic battery charger list |
|||||||||
|
ModelIDOITWELL |
Charging voltage¤t for reference |
N.W. (KG) |
Size(mm) IDOITWELL |
||||||
|
12V |
24V |
36V |
48V |
60V |
72V |
84V |
|||
|
120W |
7A |
4A |
2.5A |
1.8A |
1.5A |
_ |
_ |
0.7 |
135x90x50 |
|
180W |
10A |
5A |
3.5A |
2.5A |
2A |
1.5A |
_ |
0.9 |
155x90x50 |
|
240W |
15A |
7.5A |
5A |
3.8A |
3A |
2.5A |
_ |
1 |
170x90x50 |
|
360W |
20A |
12A |
8A |
6A |
4.5A |
4A |
_ |
1.2 |
170x90x63 |
|
600W |
25A |
19A |
12A |
9A |
7A |
6A |
_ |
2.5 |
207x120x70 |
|
900W |
40A |
25A |
18A |
15A |
12A |
10A |
_ |
3 |
220x135x70 |
|
900WB |
40A |
25A |
18A |
15A |
12A |
10A |
8A |
3.5 |
260x175x90 |
|
1200W |
50A |
30A |
20A |
19A |
15A |
12A |
10A |
4.5 |
260x175x90 |
|
1500W |
60A |
45A |
30A |
24A |
19A |
16A |
14A |
5.5 |
300x175x90 |
|
2000W |
90A |
60A |
40A |
30A |
25A |
20A |
18A |
6.5 |
330x175x115 |
|
2500W |
- |
75A |
50A |
40A |
30A |
25A |
22A |
7 |
380x240x150 |
|
4000W |
150A |
100A |
80A |
60A |
45A |
40A |
35A |
11 |
340x235x110 |
We are the professional manufacturer that produce all kinds of the battery chargers, such as VRLA, AGM, GEL, SLA lead acid battery chargers, lithium battery chargers, lifepo4 battery chargers, lipo battery chargers, etc. We can 100% custom the battery chargers according to buyer's demands. NO MOQ!!! Even if only 1 piece.
Before purchasing our battery chargers, please read the following questions and answers carefully:
The Waterproof battery charger 12V 20A 24V 12A 36V 8A 48V 7A lithium lead acid lifepo4 battery charger has designed highly reliable and meet international safety and electromagnetic compatibility requirements.
● Input Characteristics:
Input Voltage: 110Vac or 230Vac input AC voltage
Input Frequency: 50Hz or 60Hz and single phase.
● Output Characteristics:
Constant Charging Voltage:12.6V (for 3S lithium battery pack)/16.8V(for 4S lithium battery pack)
14.6V(for 4S lifepo4 battery pack)
14.7V(for 12V lead acid battery)
● Charging Mode:
Waterproof battery charger 12V 20A 24V 12A 36V 8A 48V 7A lithium lead acid lifepo4 battery charger
4 Stages,pre-charge, CC, CV, Trickle
● Safety Test for battery charger
Hi-pot Test:15KVac 5mA 3 Seconds between input and output test
Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds
Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B
● Protection for battery charger:
Over Voltage Protection The battery charger will be auto recovered when faults remove
Over Current Protection Charger output current does not exceed the set maximum battery charging current.
Over Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)
Over reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.
● DC Connector Dimension:
Waterproof battery charger 12V 20A 24V 12A 36V 8A 48V 7A lithium lead acid lifepo4 battery charger
Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.
Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc
Product Introduction
Company Information
The SKYFAVOR brand has always been committed to optimizing waterproof dc dc charger with high-tech materials and technologies. Our company has some of the world's leading researchers in the waterproof dc dc charger field. We value sustainable development. Through our manufacturing technology and our continuous study, we strive to develop human- and environment-friendly products.
Welcome to contact us.
