Product details of the smart car battery charger
Product Information
SKYFAVOR smart car battery charger is manufactured with utmost care and precision using quality-guaranteed materials and leading-edge technology. smart car battery charger's performance is in the leading position both inside and outside. High quality, low price and quick delivery are the magic weapons for Shenzhen Skyfavor Technology Co., ltd to win the market.
| Name | 60V 5A Lithium battery cherger(16S Li-ion battery) |
| Model | 360W |
| Battery type | 16S Lithium battery |
| AC Input | 110Vac or 230Vac |
| Output voltage | 67.2V |
| Output current | 5A |
| Protection | Over Voltage Protection |
| Over Current Protection | |
| Short Circuit Protection | |
| Reverse polarity Protection | |
| Apply to | For golf cart,ebike.10AH,15AH 20AH Li-ion battery |
● Input Characteristics:
Input Voltage: 100-240Vac input AC voltage
Input Frequency: 50Hz or 60Hz and single phase.
● Output Characteristics:
Constant Charging Voltage:67.2V(for 16S lithium battery)
● Charging Mode:
60 volt electric scooter battery charger 60V 5A fast automatic 16S lithium ion battery charger
3 Stages, CC, CV, Trickle
● Safety Test for battery charger
Hi-pot Test:15KVac 5mA 3 Seconds between input and output test
Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds
Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B
● Protection for battery charger
Over Voltage Protection The battery charger will be auto recovered when faults remove
Over Current Protection Charger output current does not exceed the set maximum battery charging current.
Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)
reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.
● DC Connector Dimension:
Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.
Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc
Manufacture time
The manufacture time of the battery charger will need 8-12 days, because all the battery chargers are customized according to the customer's requirements, we have not any chargers in stock. If you accept the delivery time, please go ahead to make purchase. Once you place the order, we will treat you accept the manufacture time.
Lead Time:60 volt electric scooter battery charger 60V 5A fast automatic 16S lithium ion battery charger
Normally we will deliver the battery charger by DHL, UPS or Fedex express, it always need 5-8 days on transport.
So you will receive the parcel in 13-20 days after pay for the order.
Last thing, when the order be paid it will can't be cancelled after 24 hours, as the charger is customized according to buyer's requirement, it is unique, it is impossible to change the charger specification to resell, so we don't accept order be cancelled after 24 hours. Please read above information carefully and buy with caution. Thanks for your kind understanding and support!
