Product details of the smart battery charger
Product Introduction
SKYFAVOR smart battery charger is manufactured by a team of professionals who keep track with the market trends. Our strict quality control ensures the product to meet with the industry quality standard. SKYFAVOR – a famous brand of smart battery charger, proudly designs and produces smart battery charger.
| Name | Universal 12V battery charger 12V 30A on board Multi-function 12 volt battery charger |
| Model | 1230ATOD |
| Input voltage & frequency range | 100V-240Vac |
| battery type | GEL,Sealed,Flooded/AGM,Lifepo4,Lithium-ion(NCM) |
| Battery voltage | 12V |
| Max output current-Nomal mode | 30A |
| Max output current-low current mode | 15A |
| Max output current Night mode (Quiet mode,10% fan RPM) | 10A |
| Power supply function(Default output voltage value) | 12.6V 30A |
| Power supply function(APP setting output voltage range) | 12V-13.8V |
| Efficiency | >90% |
| Dimension | 221X155X70mm |
| Weight | 1.4kg |
| Accessories(Optional) | Monitor(MT-2) |
| Bluetooth Dongle(BT10) | |
| Temperature Sensor(TRS) |
Product Introduction
Note:
1. Charging the lithium battery without temperature compensation
2. The temperature sensor (RTs) is an optional part and needs to be purchased separately If not connected, no temperature compensation
3. Protection function
Overheating protection: the internal temperature> 85 ℃ ,charger stop working Current reduction protection: the internal temperature > 70 ℃, the current is reduced by 50% for charging
Short circuit protection: battery is short circuited and the charger stops working
Reverse connection protection: the battery is reversely connected and the charger does not work
4. Low current mode(50% current)
The charger is charged with 50% current of standard specification
5. Night mode Universal 12V battery charger 12V 30A on board Multi-function 12 volt battery charger
Night mode charging, Keep 10% fan speed allowed during charging process, and Keep silent , the charging current will reduce to 10A (AC1230 PRO) / 6A(AC2415PRO) 3A(AC4810PRO)
6. DC Power supply mode
Charger outputs constant voltage,It can be used as a DC power supply,Reference parameter table of output voltage and current
Note: DC power supply mode, disable battery selection function and temperature compensation
7. Fan control
Detect charging current and charger temperature to change fan speed
8. Lithium battery 0V automatic activation charging
When the lithium battery is low voltage protection (UVP) state, the charger can automatically activate the lithium battery charging
9. lithium battery 0℃ charging function
The 0 ℃ charging function of lithium battery can be selected through the DIP switch"
Product Introduction
Company Advantage
• Our company has a professional and efficient team. Based on advanced production concepts, our team members have created a batch of quality products for our company. They are the driving force for our company's efficient and rapid development.
• Skyfavor focuses on the internal management and opens up the market. We actively explore innovative thinking and fully introduce modern management mode. We continuously achieve development in the competition based on strong technical capability, high-quality products, and comprehensive and thoughtful services.
• Skyfavor's location enjoys advantageous geographic condition with open and unimpeded traffic access. This creates convenience for us to deliver various Battery charger in time.
Skyfavor provides lots of new trendy Battery charger for you to choose. Contact us if in you have any needs!
