Product details of the portable charger for car
Quick Overview
The design and production techniques of SKYFAVOR portable charger for car are competitive in the industry. This product has achieved world-class standards of quality and cost performance ratio. Matching unparalleled service team with prime portable charger for car helps SKYFAVOR to be a leading enterprise in the market.
Product Introduction
The portable charger for car produced by our company have superior quality, and the specific details of products are presented in the following section.
|
Name |
6V 9V 12V voltage Adjustable battery charger 12V 9V 6V Universal lead acid battery charger |
|
Mode |
060912 |
|
Input |
110Vac or 220Vac |
|
Output |
7.2V 10.8V 14.4V |
|
Output current |
6V 9V 12V 2A |
|
Features: |
folat charge |
|
Compatibility |
4AH-40AH lead acid battery |
|
Protection |
-Short circuit protection -Low-voltage protection -Overvoltage protection -Overcurrent protection -Overheating protection -Smart security protection -Overall earthquake resistance -Overcharge and overdischarge protection -Reverse connection protection -Overshoot over discharge protection |
|
Apply to |
Children's toy cars, motorcycles,etc. |
|
weight |
430g |
6V 9V 12V voltage Adjustable battery charger 12V 9V 6V Universal lead acid battery charger
The 6V 9V 12V voltage Adjustable battery charger 12V 9V 6V Universal lead acid battery charger has designed highly reliable and meet international safety and electromagnetic compatibility requirements.
A:Input Characteristics:
Input Voltage: 100-240Vac input AC voltage
Input Frequency: 50Hz or 60Hz and single phase.
B:Output Characteristics:
Constant Charging Voltage: 7.2V(for 6v lead acid battery)
10.8V(for 9V lead acid battery),
14.4V(for 12V Lead acid battery)
C:Charging Mode:360W series 12V 20A 24V 12A 36V 8A 48V 6A 60V 5A 72V 4.5A 84V 3A battery charger
3 Stages, CC, CV, Trickle
D:Safety Test for battery charger
Hi-pot Test:15KVac 5mA 3 Seconds between input and output test
Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds
Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B
E:Protection for battery charger
Over Voltage Protection The batteries charger will be auto recovered when faults remove
Over Current Protection Charger output current does not exceed the set maximum battery charging current.
Over Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)
Over reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.
F:DC Connector Dimension:360W series 12V 20A 24V 12A 36V 8A 48V 6A 60V 5A 72V 4.5A 84V 3A battery charger
Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.
Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc
6V 9V 12V voltage Adjustable battery charger 12V 9V 6V Universal lead acid battery charger
Other models
Smart Automatic battery charger list |
|||||||||
|
Model |
Charging voltage¤t for reference |
N.W. (KG) |
Size(mm) |
||||||
|
84V |
|||||||||
|
7A |
4A |
2.5A |
1.8A |
1.5A |
_ |
_ |
0.7 |
135x90x50 |
|
|
10A |
5A |
3.5A |
2.5A |
2A |
1.5A |
_ |
0.9 |
155x90x50 |
|
|
15A |
7.5A |
5A |
3.8A |
3A |
2.5A |
_ |
1 |
170x90x50 |
|
|
20A |
12A |
8A |
6A |
4.5A |
4A |
_ |
1.2 |
170x90x63 |
|
|
25A |
19A |
12A |
9A |
7A |
6A |
_ |
2.5 |
207x120x70 |
|
|
40A |
25A |
18A |
15A |
12A |
10A |
_ |
3 |
220x135x70 |
|
|
40A |
25A |
18A |
15A |
12A |
10A |
8A |
3.5 |
260x175x90 |
|
|
50A |
30A |
20A |
19A |
15A |
12A |
10A |
4.5 |
260x175x90 |
|
|
60A |
45A |
30A |
24A |
19A |
16A |
14A |
5.5 |
300x175x90 |
|
|
90A |
60A |
40A |
30A |
25A |
20A |
18A |
6.5 |
330x175x115 |
|
|
- |
75A |
50A |
40A |
30A |
25A |
22A |
7 |
380x240x150 |
|
|
150A |
100A |
80A |
60A |
45A |
40A |
35A |
11 |
340x235x110 | |
