Personalized Battery Charger - - SKYFAVOR-6
Product details of the personalized battery charger
Product Description
SKYFAVOR personalized battery charger is finished efficiently from material selection to packaging. This product is highly demanded worldwide due to its wide range of functions and specifications. If there is any problem for quality of personalized battery charger, Shenzhen Skyfavor Technology Co., ltd promises full refund.
Product Details
| Charger Model: | 900A | Power: | 900W |
| Housing: | Aluminium Alloy | Size: | 262*88.5*161.8mm |
| Communication: | CAN, RS485 | Waterproof: | IP65 |
| Efficiency: | >=92% | Operating Temperature: | -20 to 40℃ |
| Storage Temperature: | -40 to +70℃ | Noise: | <=40dB |
| Cooling: | Temperature and load current-controlled fan | ||
| Protection: | Over-temperature, over-voltage, over-current, short-circuit, | ||
| and reverse connection protection. | |||
| Battery type: | Suitable for lead-acid batteries (water-added, GEL, and AGM) or lithium batteries (lithium-iron, lithium-manganese, lithium ternary) charging. | ||
| Features: | 1.Automatic multi-stage charging curve for long battery life 2.Intelligent fully automatic charging: obtains the battery status | ||
| and switches the charging mode(charge wait/pre-charge/constant current/constant voltage/float charge/ recharge/ full charge) | |||
Electronic Characteristics
| ITEM | 2430A | 3620A | 4815A | 6012A | 7210A | |
| Output | LFP charging voltage | 29.2V | 43.8V | 58.4V | 73.0V | 87.6V |
| NCM charging voltage | 29V | 43.5V | 58V | 67.2V | 84.0V | |
| L-A charging voltage | 29.4V | 44.1V | 58.8V | 73.5V | 88.2V | |
| Floating charge voltage | 27.6V(only Lead) | 41.4V(only Lead) | 55.2V(only Lead) | 69V(only Lead) | 82.8V(only Lead) | |
| Maximum charging current | 30A | 20A | 15.0A | 12A | 10A | |
| Rotating lamp current | Lead 5.0A/ | Lead 4.5A/ | Lead 3.75A/ | Lead 2.0A/ Lithium 0.64A | Lead 1.5A/ Lithium 0.45A | |
| Lithium 1.8A | Lithium 1.44A | Lithium 1.2A | ||||
| Ripple voltage | ≤2%VOUTMAX | |||||
| Input | Voltage range | 90V~260VAC | ||||
| Frequency range | 47~63Hz | |||||
| Power factor | PF>0.98/115VAC, PF>0.95/230VAC at full load | |||||
| AC current(type) | 12A/115VAC 6.5A/230VAC | |||||
| Inrush current(type) | COLD START 50A at 230VAC | |||||
| Leakage Current | <0.75MA | |||||
Smart 24V battery charger 24V 30A on board waterproof 24 volt battery charger
Product Introduction1.Multi-voltage compatible : manually select battery type and automatically adjust charging curve, solving the problem of different batteries requiring different chargers on the same voltage platform.2.Compatible with AGM, gel, lead-acid, NCM, LFP, lithium-ion batteries.3.Intelligent fully automatic charging: switch charging modes based on the battery's status.(Standby/precharge/constant current/constant voltage/float charge/recharge/full).Automatic multi-stage charging curve for longer battery life.4.Bluetooth application monitoring of charging status, supports custom charging time and parameter settings.5.Dimensions: 262 mm (L) x 88.5 mm (W) x 161.8 mm (H).6.CE, FCC, and DOE etc.7.Supports multiple output plugs8.Customizable charging profiles or charging modes.
We are the professional manufacturer of all kinds of the battery chargers, we can make OEM customized battery charger for every customer
Smart Automatic battery charger list | |||||||||
Model | Charging voltage¤t for reference | N.W. (KG) | Size(mm) | ||||||
84V | |||||||||
7A | 4A | 2.5A | 1.8A | 1.5A | _ | _ | 0.7 | 135x90x50 | |
10A | 5A | 3.5A | 2.5A | 2A | 1.5A | _ | 0.9 | 155x90x50 | |
15A | 7.5A | 5A | 3.8A | 3A | 2.5A | _ | 1 | 170x90x50 | |
20A | 12A | 8A | 6A | 4.5A | 4A | _ | 1.2 | 170x90x63 | |
25A | 19A | 12A | 9A | 7A | 6A | _ | 2.5 | 207x120x70 | |
40A | 25A | 18A | 15A | 12A | 10A | _ | 3 | 220x135x70 | |
40A | 25A | 18A | 15A | 12A | 10A | 8A | 3.5 | 260x175x90 | |
50A | 30A | 20A | 19A | 15A | 12A | 10A | 4.5 | 260x175x90 | |
60A | 45A | 30A | 24A | 19A | 16A | 14A | 5.5 | 300x175x90 | |
90A | 60A | 40A | 30A | 25A | 20A | 18A | 6.5 | 330x175x115 | |
- | 75A | 50A | 40A | 30A | 25A | 22A | 7 | 380x240x150 | |
150A | 100A | 80A | 60A | 45A | 40A | 35A | 11 | 400x300x200 | |
Product Introduction
Company Feature
• Skyfavor's marketing network covers all over the world.
• Since the establishment in our company has gained rich experience. Besides, our strong production capacity has been recognized by the industry.
• Skyfavor's location enjoys a comprehensive traffic network, which is good for the distribution of products.
We only produce high-quality products. Welcome customers to contact customer service staff for consultation!
