Product details of the personalized battery charger
Product Description
SKYFAVOR personalized battery charger is quite attractive with its design. The product is featured by fine finish, durability and optimal performance. Shenzhen Skyfavor Technology Co., ltd insists that company culture is the core competitive power.
Product Details
Charger Model: | 600A | Power: | 600W |
Housing: | Aluminium Alloy | Size: | 262*88.5*161.8mm |
Communication: | CAN, RS485 | Waterproof: | IP65 |
Efficiency: | >=92% | Operating Temperature: | -20 to 40℃ |
Storage Temperature: | -40 to +70℃ | Noise: | <=40dB |
Cooling: | Temperature and load current-controlled fan | ||
Protection: | Over-temperature, over-voltage, over-current, short-circuit, | ||
and reverse connection protection. | |||
Battery type: | Suitable for lead-acid batteries (water-added, GEL, and AGM) or lithium batteries (lithium-iron, lithium-manganese, lithium ternary) charging. | ||
Features: | 1.Automatic multi-stage charging curve for long battery life 2.Intelligent fully automatic charging: obtains the battery status | ||
and switches the charging mode(charge wait/pre-charge/constant current/constant voltage/float charge/ recharge/ full charge) |
ITEM | 1230A | 2420A | 3613A | 4810A | 6008A | 7206A | |
Output | LFP charging voltage | 14.6V | 29.2V | 43.8V | 58.4V | 73.0V | 87.6V |
NCM charging voltage | 16.8V | 29.4V | 42.0V | 54.6V | 67.2V | 84.0V | |
L-A charging voltage | 14.7V | 29.4V | 44.1V | 58.8V | 73.5V | 88.2V | |
Float voltage | 13.8V(only Lead) | 27.6V(only Lead) | 41.4V(only Lead) | 55.2V(only Lead) | 69V(only Lead) | 82.8V(only Lead) | |
Constant charge current | 30A | 20A | 13A | 10A | 8A | 6A | |
Rotating lamp current | Lead 7.5A/ Lithium 2.4A | Lead 5.0A/ Lithium 1.6A | Lead 3.25A/ Lithium 1.04A | Lead 2.5A/ Lithium 0.8A | Lead 2.0A/ Lithium 0.64A | Lead 1.5A/ Lithium 0.45A | |
Ripple voltage | ≤2%VOUTMAX | ||||||
Input | Voltage range | 90V~260VAC | |||||
Frequency range | 47~63Hz | ||||||
Power factor | PF>0.98/115VAC, PF>0.95/230VAC at full load | ||||||
Input current(type) | 12A/115VAC 6.5A/230VAC | ||||||
Vomit (type) | COLD START 50A at 230VAC | ||||||
Leakage Current | <0.75ma |
Universal 60V battery charger 60V 8A automatic waterproof 60 volt batteries charger
Product Introduction1.Multi-voltage compatible : manually select battery type and automatically adjust charging curve, solving the problem of different batteries requiring different chargers on the same voltage platform.2.Compatible with AGM, gel, lead-acid, NCM, LFP, lithium-ion batteries.3.Intelligent fully automatic charging: switch charging modes based on the battery's status.(Standby/precharge/constant current/constant voltage/float charge/recharge/full).Automatic multi-stage charging curve for longer battery life.4.Bluetooth application monitoring of charging status, supports custom charging time and parameter settings.5.Dimensions: 262 mm (L) x 88.5 mm (W) x 161.8 mm (H).6.CE, FCC, and DOE etc. 7.Supports multiple output plugs8.Customizable charging profiles or charging modes.
Product Introduction
Company Advantage
• Skyfavor has conducted in-depth technical exchanges and cooperation with both domestic and international R&D agencies. Besides, we have also hired a number of experts to be technical advisors and regularly organized training and exchanges. All this provides a technical guarantee for the production.
• Superior geographical location, traffic convenience, and developed communication create a good external environment for Skyfavor's development.
• Based on the local, our company looks out to the whole country. We have established sales outlets in many first and second-tier cities in China, forming a nationwide sales and service network.
Skyfavor provides massive quality industry information. Please leave your contact information and get it!
