Name	48 volt lithium battery charger 48V 5A automatic 12S lithium li ion battery charger
Model	300W
Battery type	48V 12S lithium battery
AC Input	110Vac or 230Vac
Output voltage	50.4V
Output current	5A
Protection	Over Voltage Protection Over Current Protection Short Circuit Protection Reverse polarity Protection
Apply to	For 12AH,15AH,20AH 48V 12S lithium battery

48 volt lithium battery charger 48V 5A automatic 12S lithium li ion battery charger

The 48 volt lithium battery charger 48V 5A automatic 12S lithium li ion battery charger has designed highly reliable and meet international safety and electromagnetic compatibility requirements.

A:Input Characteristics:

Input Voltage: 110v or 230Vac input AC voltage

Input Frequency: 50Hz or 60Hz and single phase.

B:Output Characteristics:

Constant Charging Voltage: 50.4V(for 48V 12S lithium battery)

C:Charging Mode48 volt lithium battery charger 48V 5A automatic 12S lithium li ion battery charger

3 Stages, CC, CV, Trickle

D:Safety Test for battery charger

Hi-pot Test:15KVac 5mA 3 Seconds between input and output test

Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds

Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B

E:Protection for battery charger

Over Voltage Protection The battery charger will be auto recovered when faults remove

Over Current Protection Charger output current does not exceed the set maximum battery charging current.

Over Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)

Over reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.

F:DC Connector Dimension:48 volt lithium battery charger 48V 5A automatic 12S lithium li ion battery charger

Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.

Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc

We are the professional manufacturer of all kinds of the battery chargers, such as SLA, AGM,GEL lead-acid battery charger, lithium battery charger, lifepo4 battery charger, etc. We can customize all kinds of battery charger for every customer, any quantity is ok.

Each charger only can charge for one kind battery, such as if you choose lead acid battery, we will manufacture the lead acid battery charger, it will not work for lithium battery or lifepo4 battery. Because different kind battery charger the charging curve is different.

Manufacture time:

The manufacture time of the battery charger will need 7-14 days, because all the battery chargers are customized according to the customer's requiremen ts, we have not any chargers in stock. If you accept the delivery time, please go ahead to make purchase. Once you place the order, we will believe you accept the manufacture time.

Lead Time:48 volt lithium battery charger 48V 5A automatic 12S lithium li ion battery charger

Normally we will deliver the battery charger by DHL, UPS or FEDEX express, it always need 5-8 days on transport.

So you will receive the parcel in 12-22 days after pay for the order.

Last thing, when the order be paid it will can't be cancelled after 24 hours, as the charger is customized according to buyer's requirement, it is unique, it is impossible to change the charger specification to resell, so we don't accept order be cancelled after 24 hours. Please read above information carefully and buy with caution. Thanks for your kind understanding and support!

We are the professional manufacturer of all kinds of the battery chargers, we can make OEM customized battery charger for every customer

Smart Automatic battery charger list
Model	Charging voltage&current for reference							N.W. (KG)	Size(mm)
Model	12V	24V	36V	48V	60V	72V	84V	N.W. (KG)	Size(mm)
120W	7A	4A	2.5A	1.8A	1.5A	_	_	0.7	135x90x50
180W	10A	5A	3.5A	2.5A	2A	1.5A	_	0.9	155x90x50
240W	15A	7.5A	5A	3.8A	3A	2.5A	_	1	170x90x50
360W	20A	12A	8A	6A	4.5A	4A	_	1.2	170x90x63
600W	25A	19A	12A	9A	7A	6A	_	2.5	207x120x70
900W	40A	25A	18A	15A	12A	10A	_	3	220x135x70
900WB	40A	25A	18A	15A	12A	10A	8A	3.5	260x175x90
1200W	50A	30A	20A	19A	15A	12A	10A	4.5	260x175x90
1500W	60A	45A	30A	24A	19A	16A	14A	5.5	300x175x90
2000W	90A	60A	40A	30A	25A	20A	18A	6.5	330x175x115
2500W	-	75A	50A	40A	30A	25A	22A	7	380x240x150
4000W	150A	100A	80A	60A	45A	40A	35A	11	340x235x110

Product Introduction

bf01f4dc498fb4a247a910830dc6a05

38d1216dae75ce44788efc12989c2e7

cd012ba02c3d81d4940f81a3e2d5e63

d486c3049051b693860380607179add

f48ad80f02c5e73f6b2d45f28c22f08

6e549f562f593b264849e465e8ae88a

1d1b6108b314ca3bc6b99b12cd9df50

01da446c987e216b5e729d50970c493

Company Advantages

· golf cart battery charger is designed by industry's leading designers.

· To rule out every possibility of defect, the product is subject to the thorough inspection conducted by professional quality inspectors.

· Shenzhen Skyfavor Technology Co., ltd has a highly qualified team that loves golf cart battery charger development.

Company Features

· Shenzhen Skyfavor Technology Co., ltd has been focusing on the production of high-quality golf cart battery charger since inception.

· The quality of golf cart battery charger can be guaranteed by our experienced technicians.

· SKYFAVOR will place a lot of emphasis on golf cart battery charger in the future. Get an offer!

Application of the Product

golf cart battery charger is one of the main products of Skyfavor. With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers.

While providing excellent products, Skyfavor is dedicated to providing personalized solutions for customers according to their needs and actual situations.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.

Original Lvtong golf cart battery charger 72V 25A Automatic lead acid battery charger for lvtong electric vehicle intelligent charger

Professional 48V golf cart charger 48V 25A Maintenance free lead acid battery charger Y60 Connector charger for 48V golf cart

AC 110V TO 48V waterproof battery charger 48V 20A automatic fast 48 volt golf cart charger with trickle charge for EZGO CLUB CAR

Professional 48V golf cart battery charger 48V 15A smart waterproof EZGO CLUB CAR TXT RXV golf cart charger with trickle charge

Custom fast golf cart battery charger 48v 9a lead acid battery charger High quality Automatic 48V deep cycle battery charger
