Golf Cart Battery Charger by SKYFAVOR-2

(Car Battery Charger)Smart mini 12V 24V battery charger 12V 24V 25A 20A 15A 10A 5A Adjustable current high power lead acid lifepo4 battery charger

FEATURES:

·       High Frequency pulse intelligent repair can solve the problems of insufficient power, low voltage and large internal resistance. The staged charging can effectively protect the battery from damage and prolong the battery life.

·       The LED intelligent digital display screen can automatically pulse repair the batteries, and it will automatically stop when fully charged. and intelligently adjust the current.

·       375W pure copper high-frequency transformer, high conversion rate, safe and fast, equipped with exhaust port design, fast and silent heat dissipation, not easy to heat, greatly extending the service life of the charger.

·       Multi intelligent protections, reverse connection, short circuit, overvoltage, overcurrent, overheating, low voltage protection to ensure safety, equipped with copper-plated alligator clips, using oxidation copper plating process, high temperature resistance, good conductivity.

·       Wide range of adaptation, suitable for all kinds of batteries, common for automobiles and motorcycles.

·       Universal for Lead Acid GM GEL Wet batteries and LIFEPO4 batteries (only for lithium iron phosphate batteries with BMS protection board. )

Specification:

·       Item: Car Battery Charger

·       Model: 122425A

·       Material: Plastic,metal, electronic components

·       Power: 375W

·       Input voltage: 100V-240V 50/60HZ

·       Output voltage: 12V~15.5V/24V~31V

·       Output current: DC12V 5~25A/24V 5~10A (Max)

·       Frequency: 50/60Hz

·       Plug specifications: EU plug,US plug

·       Application:  for 12V 25Ah-800Ah / 24V 25Ah-400Ah Lead Acid GM GEL Wet batteries and LIFEPO4 batteries (with BMS protection board)

We are the professional manufacturer of all kinds of the battery chargers, such as SLA, AGM,GEL lead-acid battery charger, lithium battery charger, lifepo4 battery charger, etc. We can customize all kinds of battery charger for every customer, any quantity is ok.

Each charger only can charge for one kind battery, such as if you choose lead acid battery, we will manufacture the lead acid battery charger, it will not work for lithium battery or lifepo4 battery. Because different kind battery charger the charging curve is different.

Smart Automatic battery charger list
Model	Charging voltage&current for reference							N.W. (KG)	Size(mm)
	12V	24V	36V	48V	60V	72V	84V
120W	7A	4A	2.5A	1.8A	1.5A	_	_	0.7	135x90x50
180W	10A	5A	3.5A	2.5A	2A	1.5A	_	0.9	155x90x50
240W	15A	7.5A	5A	3.8A	3A	2.5A	_	1	170x90x50
360W	20A	12A	8A	6A	4.5A	4A	_	1.2	170x90x63
600W	25A	19A	12A	9A	7A	6A	_	2.5	207x120x70
900W	40A	25A	18A	15A	12A	10A	_	3	220x135x70
900WB	40A	25A	18A	15A	12A	10A	8A	3.5	260x175x90
1200W	50A	30A	20A	19A	15A	12A	10A	4.5	260x175x90
1500W	60A	45A	30A	24A	19A	16A	14A	5.5	300x175x90
2000W	90A	60A	40A	30A	25A	20A	18A	6.5	330x175x115
2500W	-	75A	50A	40A	30A	25A	22A	7	380x240x150
4000W	150A	100A	80A	60A	45A	40A	35A	11	400x300x200

 Product Introduction

09de2f5dd3c79af304109d541b98e29

9f647143e34182eff6bebe094dcae66

2a18b35be4d460483f38a21e335209f

786d3f1f6a7e102b5da4e167a6895ca

842ac031e81aac9d61f9eddbd9fbc59

d307607e72e599a5bdfe536614ba0c8

dbf9ff738088ef60d1e64911b5273dd

Company Advantages

· SKYFAVOR golf cart battery charger is manufactured using top-notch materials in conformity with the industry quality standards.

· The product has the advantage of long service life.

· Shenzhen Skyfavor Technology Co., ltd is committed to provide swift delivery, full quality service and tracking service for its costumers.

Company Features

· SKYFAVOR manufacturer is a particularly popular golf cart battery charger manufacturer.

· The SKYFAVOR factory uses advanced production equipment and testing equipment.

· SKYFAVOR continues to stick to the principle of client first. Please contact us!

Application of the Product

Multiple in function and wide in application, golf cart battery charger can be used in many industries and fields.

Skyfavor insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.
