Dc to Dc Charger Lithium by SKYFAVOR
Company Advantages
· SKYFAVOR dc to dc charger lithium is offered with the help of talented team of craftsmen.
· The product has an exceptional and stable quality thanks to the implementation of the scientific quality management system.
· Shenzhen Skyfavor Technology Co., ltd is well-known at home and abroad for its fabulous quality and solid packing. .
| Name | 12V battery to battery charger 12V 90A FAST automatic smart 12 votl RV DC TO DC Charger |
| Model | 1290BTOB |
| Main Battery voltage | 12V |
| Main battery type | GEL,Sealed,Flooded/AGM,Lifepo4,Lithium-ion(NCM) |
| Starter battery voltage | 12V |
| Starter battery type | Lead acid |
| DC-DC Max charging power | 1350W |
| Main battery Max charging current | 90A |
| Self-consumption current | 24ma |
| Dimension | 241X190X72mm |
| Weight | 2kg |
|
Accessories(Optional) |
Monitor(MT2) Bluetooth Dongle(BT10) Temperature Sensor(TRS) |
12V battery to battery charger 12V 90A FAST automatic smart 12 votl RV DC TO DC Charger
This is a automatic DC-DC charger that can charge the main battery through the and starter battery, or Solar panels charge the main battery (some models), DC-DC battery charger designed specifically for motorhomes, campers, ships, etc.
B2B Charge:
It means to charge the main battery through alternator and starter battery. If it is not used in the vehicle, you can also use one battery to charge another battery
1. When the vehicle is running, the vehicle alternator can quickly charge the main battery through the charger at full power
2. The charger can charge the main battery according to the specified voltage and current by boosting or stepping down to ensure that the main battery is in accordance with the standard.
12V battery to battery charger 12V 90A FAST automatic smart 12 votl RV DC TO DC Charger
Other functions
1. Fully automatic charging: In order to continuously charge the battery, the controller can always be connected to the car battery. When the charging energy is stopped, such as the car stops driving, the battery will not discharge in the reverse direction.
2. Multiple protection functions: with overheating, overvoltage, short circuit, wrong connection protection
3.External temperature sensor: The ambient temperature will affect the parameters for charging the battery. The controller needs to perform parameter compensation according to the temperature of the battery, especially in places with large temperature changes. It is strongly recommended to install a temperature sensor.
Note: Lithium batteries do not require temperature compensation
4. Lithium battery automatic wake-up function: When the lithium battery BMS is protected for some reason, the controller can automatically wake up the BMS and continue to charge the lithium battery
!Battery life and efficiency
1 Ensure that the battery installation environment is ventilated and dissipated. The LiFePO4 battery is recommended to work in an environment above 0 degrees Celsius, otherwise the battery characteristics will drop a lot
2. The battery must be fully charged and stored, and it must be charged regularly to ensure that it is not stored under power, otherwise it will affect the battery life
3. Lead-acid batteries that are completely empty must be charged as soon as possible, otherwise it may cause permanent damage!
4. The lithium battery must have a BMS (Battery Management System). Try to avoid completely emptying the battery.
12V battery to battery charger 12V 90A FAST automatic smart 12 votl RV DC TO DC Charger
We are the professional manufacturer of all kinds of the battery chargers, such as SLA, AGM,GEL lead-acid battery charger, lithium battery charger, lifepo4 battery charger, etc. We can customize all kinds of battery charger for every customer, any quantity is ok.
Smart Automatic battery charger list | |||||||||
Model | Charging voltage¤t for reference | N.W. (KG) | Size(mm) | ||||||
84V | |||||||||
7A | 4A | 2.5A | 1.8A | 1.5A | _ | _ | 0.7 | 135x90x50 | |
10A | 5A | 3.5A | 2.5A | 2A | 1.5A | _ | 0.9 | 155x90x50 | |
15A | 8.5A | 5A | 3.8A | 3A | 2.5A | _ | 1 | 170x90x50 | |
20A | 12A | 8A | 6A | 4.5A | 4A | _ | 1.2 | 170x90x63 | |
25A | 19A | 12A | 9A | 7A | 6A | _ | 2.5 | 207x120x70 | |
40A | 25A | 18A | 15A | 12A | 10A | _ | 3 | 220x135x70 | |
40A | 25A | 18A | 15A | 12A | 10A | 8A | 3.5 | 260x175x90 | |
50A | 30A | 20A | 19A | 15A | 12A | 10A | 4.5 | 260x175x90 | |
60A | 45A | 30A | 24A | 19A | 16A | 14A | 5.5 | 300x175x90 | |
90A | 60A | 40A | 30A | 25A | 20A | 18A | 6.5 | 330x175x115 | |
- | 75A | 50A | 40A | 30A | 25A | 22A | 7 | 380x240x150 | |
150A | 100A | 80A | 60A | 45A | 40A | 35A | 11 | 400x300x200 | |
Product Introduction
Company Features
· Shenzhen Skyfavor Technology Co., ltd is a trustworthy manufacturer and supplier of dc to dc charger lithium. We have received a good reputation in the industry.
· In terms of technology, Shenzhen Skyfavor Technology Co., ltd has its own R&D team and intellectual property. Shenzhen Skyfavor Technology Co., ltd has a professional, stable, young and experienced R&D team.
· Skyfavor is committed to helping our customers get the best value. Please contact us!
Product Details
Skyfavor's dc to dc charger lithium is processed based on advanced technology. It has excellent performances in the following details.
Application of the Product
The dc to dc charger lithium produced by Skyfavor can be used in many fields.
With a focus on customers' potential needs, Skyfavor provides customers with one-stop solutions.
Enterprise Advantages
Skyfavor has a dedicated and diligent senior management team and a large number of professional technical personnel. All this makes favorable conditions for company development.
Skyfavor is able to provide comprehensive and efficient services and solve customers' problems depending on a professional service team.
Our company sticks to the core value of 'high level, high quality and high value' and we seize the opportunity and develop with the times. Based on the enterprise spirit of 'toughness, perseverance and tenacity', we are looking forward to cooperating with more outstanding peers and creating a wonderful future.
Since the establishment in Skyfavor has been focusing on the strength improvement for years. So far we have accumulated rich industry experience.
Skyfavor's Battery charger enjoy a broad market, which are currently sold well in various regions at home and abroad.
