Dc to Dc Charger 12v to 24v by SKYFAVOR
Product details of the dc to dc charger 12v to 24v
Quick Overview
Tested by relevant national departments, dc to dc charger 12v to 24v has excellent performance that meets the national standards. Moreover, the careful design of professionals makes it compact in structure and easy to install and disassemble. The design of dc to dc charger 12v to 24v has something of significance for the further development of SKYFAVOR. The performance and durability of the product have been greatly improved through our continuous R&D efforts. dc to dc charger 12v to 24v, excellent in quality, is often used in automobiles, motorcycles, tractors, diesel engines and other products. The product is now widely used by people from various fields.
Product Introduction
With a focus on every detail of dc to dc charger 12v to 24v, we strive to create high-quality products.
|
Name |
12V DC to DC battery charger 12V 30A MPPT Solar and 12 volt battery to battery charger |
|
Model |
123020BS |
|
Main Battery voltage |
12V |
|
Main battery type |
GEL,Sealed,Flooded/AGM,Lifepo4,Lithium-ion(NCM) |
|
Starter battery voltage |
12V |
|
Starter battery type |
Lead acid |
|
DC-DC Max charging current |
30A |
|
Solar Max charging current |
20A |
|
Solar Max voltage |
50V |
|
Self-consumption current |
24ma |
|
Dimension |
190X194X70mm |
|
Weight |
1.44kg |
|
Accessories(Optional) |
Monitor(MT-2) Bluetooth Dongle(BT10) Temperature Sensor(TRS) |
B2B Charge:
It means to charge the main battery through alternator and starter battery. If it is not used in the vehicle, you can also use one battery to charge another battery
1. When the vehicle is running, the vehicle alternator can quickly charge the main battery through the charger at full power
2. The charger can charge the main battery according to the specified voltage and current by boosting or stepping down to ensure that the main battery is in accordance with the standard.
12V 30A DC to DC Dual Input Battery Charger 12V DC and MPPT solar battery charger
MPPT solar charger
1.The charger can increase the charging efficiency of the solar panel by 10-30% through MPPT technology (search for the maximum power point)
2. The charger can charge the main battery according to the specified current by boosting or stepping down to ensure that the main battery is charged according to the standard charge curve charging
3. When the vehicle is not used for a long time, you can maintain a small trickle charge flow for the starter battery to ensure that the starter battery has enough electricity to start the vehicle
12V 30A DC to DC Dual Input Battery Charger 12V DC and MPPT solar battery charger
Other functions
1. Fully automatic charging: In order to continuously charge the battery, the controller can always be connected to the car battery. When the charging energy is stopped, such as the car stops driving, the battery will not discharge in the reverse direction.
2. Multiple protection functions: with overheating, overvoltage, short circuit, wrong connection protection
3.External temperature sensor: The ambient temperature will affect the parameters for charging the battery. The controller needs to perform parameter compensation according to the temperature of the battery, especially
Product Introduction
Company Advantages
As an internationally competitive company, Shenzhen Skyfavor Technology Co., ltd has a large factory to produce dc to dc charger 12v to 24v. We have a team of talented engineers and craftsmen. They are committed to the quality of our products and are always seeking ways to improve the quality of our products including dc to dc charger 12v to 24v. Shenzhen Skyfavor Technology Co., ltd will continuously carry out strategic innovation and market innovation. Please contact us!
Consulting and order from friends of all walks of life are welcomed!
