Product details of the custom battery chargers
Product Introduction
All materials SKYFAVOR custom battery chargers uses have to go through strict quality and performance testings. To ensure durability, our highly skilled QC professionals strictly inspect the products. Shenzhen Skyfavor Technology Co., ltd can undertake customer specified delivery.
Product Details
| Charger Model: | 900A | Power: | 900W |
| Housing: | Aluminium Alloy | Size: | 262*88.5*161.8mm |
| Communication: | CAN, RS485 | Waterproof: | IP65 |
| Efficiency: | >=92% | Operating Temperature: | -20 to 40℃ |
| Storage Temperature: | -40 to +70℃ | Noise: | <=40dB |
| Cooling: | Temperature and load current-controlled fan | ||
| Protection: | Over-temperature, over-voltage, over-current, short-circuit, | ||
| and reverse connection protection. | |||
| Battery type: | Suitable for lead-acid batteries (water-added, GEL, and AGM) or lithium batteries (lithium-iron, lithium-manganese, lithium ternary) charging. | ||
| Features: | 1.Automatic multi-stage charging curve for long battery life 2.Intelligent fully automatic charging: obtains the battery status | ||
| and switches the charging mode(charge wait/pre-charge/constant current/constant voltage/float charge/ recharge/ full charge) | |||
Electronic Characteristics
| ITEM | 2430A | 3620A | 4815A | 6012A | 7210A | |
| Output | LFP charging voltage | 29.2V | 43.8V | 58.4V | 73.0V | 87.6V |
| NCM charging voltage | 29V | 43.5V | 58V | 67.2V | 84.0V | |
| L-A charging voltage | 29.4V | 44.1V | 58.8V | 73.5V | 88.2V | |
| Floating charge voltage | 27.6V(only Lead) | 41.4V(only Lead) | 55.2V(only Lead) | 69V(only Lead) | 82.8V(only Lead) | |
| Maximum charging current | 30A | 20A | 15.0A | 12A | 10A | |
| Rotating lamp current | Lead 5.0A/ | Lead 4.5A/ | Lead 3.75A/ | Lead 2.0A/ Lithium 0.64A | Lead 1.5A/ Lithium 0.45A | |
| Lithium 1.8A | Lithium 1.44A | Lithium 1.2A | ||||
| Ripple voltage | ≤2%VOUTMAX | |||||
| Input | Voltage range | 90V~260VAC | ||||
| Frequency range | 47~63Hz | |||||
| Power factor | PF>0.98/115VAC, PF>0.95/230VAC at full load | |||||
| AC current(type) | 12A/115VAC 6.5A/230VAC | |||||
| Inrush current(type) | COLD START 50A at 230VAC | |||||
| Leakage Current | <0.75MA | |||||
Waterproof 48V battery charger 48V 15A smart Universal 48 volt power battery charger
Product Introduction1.Multi-voltage compatible : manually select battery type and automatically adjust charging curve, solving the problem of different batteries requiring different chargers on the same voltage platform.2.Compatible with AGM, gel, lead-acid, NCM, LFP, lithium-ion batteries.3.Intelligent fully automatic charging: switch charging modes based on the battery's status.(Standby/precharge/constant current/constant voltage/float charge/recharge/full).Automatic multi-stage charging curve for longer battery life.4.Bluetooth application monitoring of charging status, supports custom charging time and parameter settings.5.Dimensions: 262 mm (L) x 88.5 mm (W) x 161.8 mm (H).6.CE, FCC, and DOE etc. 7.Supports multiple output plugs8.Customizable charging profiles or charging modes.
We are the professional manufacturer of all kinds of the battery chargers, we can make OEM customized battery charger for every customer
Smart Automatic battery charger list |
|||||||||
|
Model |
Charging voltage¤t for reference |
N.W. (KG) |
Size(mm) |
||||||
|
84V |
|||||||||
|
7A |
4A |
2.5A |
1.8A |
1.5A |
_ |
_ |
0.7 |
135x90x50 |
|
|
10A |
5A |
3.5A |
2.5A |
2A |
1.5A |
_ |
0.9 |
155x90x50 |
|
|
15A |
7.5A |
5A |
3.8A |
3A |
2.5A |
_ |
1 |
170x90x50 |
|
|
20A |
12A |
8A |
6A |
4.5A |
4A |
_ |
1.2 |
170x90x63 |
|
|
25A |
19A |
12A |
9A |
7A |
6A |
_ |
2.5 |
207x120x70 |
|
|
40A |
25A |
18A |
15A |
12A |
10A |
_ |
3 |
220x135x70 |
|
|
40A |
25A |
18A |
15A |
12A |
10A |
8A |
3.5 |
260x175x90 |
|
|
50A |
30A |
20A |
19A |
15A |
12A |
10A |
4.5 |
260x175x90 |
|
|
60A |
45A |
30A |
24A |
19A |
16A |
14A |
5.5 |
300x175x90 |
|
|
90A |
60A |
40A |
30A |
25A |
20A |
18A |
6.5 |
330x175x115 |
|
|
- |
75A |
50A |
40A |
30A |
25A |
22A |
7 |
380x240x150 |
|
|
150A |
100A |
80A |
60A |
45A |
40A |
35A |
11 |
400x300x200 | |
