Car Battery Charger and Jump Starter - - SKYFAVOR-2
Product details of the car battery charger and jump starter
Quick Detail
SKYFAVOR car battery charger and jump starter has experienced a well-designed process. We have organized a quality circle to detect and solve any quality problems in the production process, effectively ensuring the quality of the products. SKYFAVOR has enough storage capacity to offer mass production of car battery charger and jump starter.
Product Information
Our car battery charger and jump starter is more competitive than similar products, as shown in the following aspects.
|
Name |
Motorcycle 12V battery charger 12V 2A Automatic fast Pulse Repair lead acid batteries charger |
|
Mode |
1202E |
|
Input |
110Vac or 220Vac |
|
Output |
12V (8-14.5V) |
|
Output current |
12V 2A |
|
Features: |
Intelligent Pulse Repair |
|
Compatibility |
4AH-40AH lead acid battery |
|
Protection |
-Short circuit protection -Low-voltage protection -Overvoltage protection -Overcurrent protection -Overheating protection -Smart security protection -Overall earthquake resistance -Overcharge and overdischarge protection -Reverse connection protection -Overshoot over discharge protection |
|
Apply to |
Children's toy cars, motorcycles,etc. |
|
weight |
450g |
Motorcycle 12V battery charger 12V 2A Automatic fast Pulse Repair lead acid batteries charger
The Motorcycle 12V battery charger 12V 2A Automatic fast Pulse Repair lead acid batteries charger has designed highly reliable and meet international safety and electromagnetic compatibility requirements.
A:Input Characteristics:
Input Voltage: 100-240Vac input AC voltage
Input Frequency: 50Hz or 60Hz and single phase.
ac/50Hz(Typical full load)
B:Output Characteristics:
Constant Charging Voltage: 14.4V Float charge 13.8V
C:Charging Mode Motorcycle 12V battery charger 12V 2A Automatic fast Pulse Repair lead acid batteries charger
3 Stages, CC, CV, Trickle
D:Safety Test for battery charger
Hi-pot Test:15KVac 5mA 3 Seconds between input and output test
Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds
Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B
E:Protection for battery charger
Over Voltage Protection The battery charger will be auto recovered when faults remove
Over Current Protection Charger output current does not exceed the set maximum battery charging current.
Over Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)
Over reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.
F:DC Connector Dimension:Motorcycle 12V battery charger 12V 2A Automatic fast Pulse Repair lead acid batteries charger
Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.
Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc
Smart Automatic battery charger list |
|||||||||
|
Model |
Charging voltage¤t for reference |
N.W. (KG) |
Size(mm) |
||||||
|
84V |
|||||||||
|
7A |
4A |
2.5A |
1.8A |
1.5A |
_ |
_ |
0.7 |
135x90x50 |
|
|
10A |
5A |
3.5A |
2.5A |
2A |
1.5A |
_ |
0.9 |
155x90x50 |
|
|
15A |
7.5A |
5A |
3.8A |
3A |
2.5A |
_ |
1 |
170x90x50 |
|
|
20A |
12A |
8A |
6A |
4.5A |
4A |
_ |
1.2 |
170x90x63 |
|
|
25A |
19A |
12A |
9A |
7A |
6A |
_ |
2.5 |
207x120x70 |
|
|
40A |
25A |
18A |
15A |
12A |
10A |
_ |
3 |
220x135x70 |
|
|
40A |
25A |
18A |
15A |
12A |
10A |
8A |
3.5 |
260x175x90 |
|
|
50A |
30A |
20A |
19A |
15A |
12A |
10A |
4.5 |
260x175x90 |
|
|
60A |
45A |
30A |
24A |
19A |
16A |
14A |
5.5 |
300x175x90 |
|
|
90A |
60A |
40A |
30A |
25A |
20A |
18A |
6.5 |
330x175x115 |
|
|
- |
75A |
50A |
40A |
30A |
25A |
22A |
7 |
380x240x150 |
|
|
150A |
100A |
80A |
60A |
45A |
40A |
35A |
11 |
340x235x110 | |
