Product details of the battery chargers manufacturer
Product Introduction
Motivated by different styles of design, our designers have successfully worked out fashionable battery chargers manufacturer. Our battery chargers manufacturer can work for non-stop 24 hours. With so many advantages, lots of customers have made repeat purchases, showing the great market potential of this product.
|
Name |
Custom 60V lithium battery charger 60V 35A automatic waterproof lithium ion lipo battery charger |
|
Model |
3000W |
|
Battery type |
60V lithium battery pack |
|
AC Input |
230Vac |
|
Output voltage |
67.2V(for 16S lithium battery)/71.4V(for 17S lithium batttery) |
|
Output current |
35A |
|
Protection |
Over Voltage Protection Over Current Protection Short Circuit Protection Reverse polarity Protection |
|
Apply to |
For 100AH 120Ah 150AH, 60V lithium battery |
Custom 60V lithium battery charger 60V 35A automatic waterproof lithium ion lipo battery charger
The Custom 60V lithium battery charger 60V 35A automatic waterproof lithium ion lipo battery charger has designed highly reliable and meet international safety and electromagnetic compatibility requirements.
A:Input Characteristics:
Input Voltage: 230Vac input AC voltage
Input Frequency: 50Hz or 60Hz and single phase.
B:Output Characteristics:
Constant Charging Voltage: 67.2V(for 16S lithium battery)/71.4V(for 17S lithium batttery)
C:Charging Mode:Custom 60V lithium battery charger 60V 35A automatic waterproof lithium ion lipo battery charger
4 Stages,pre-charge, CC, CV, Trickle
D:Safety Test for battery charger
Hi-pot Test:15KVac 5mA 3 Seconds between input and output test
Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds
Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B
E:Protection for battery charger
Over Voltage Protection The battery charger will be auto recovered when faults remove
Over Current Protection Charger output current does not exceed the set maximum battery charging current.
Over Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)
Over reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.
F:DC Connector Dimension:Custom 60V lithium battery charger 60V 35A automatic waterproof lithium ion lipo battery charger
Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.
Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc
We are the professional manufacturer of all kinds of the battery chargers, we can make OEM customized battery charger for every customer
