25 Amp Dc to Dc Charger Wholesale - SKYFAVOR
Product details of the 25 amp dc to dc charger
Quick Overview
25 amp dc to dc charger has a terminal protective cap to effectively protect the terminal and reduce the terminal loss rate. In addition, it has good corrosion resistance. The production SKYFAVOR 25 amp dc to dc charger is efficient enough to meet your manufacturing needs, no matter the scale of production. This product achieves both rich functionality and superior quality. 25 amp dc to dc charger, excellent in quality, is often used in automobiles, motorcycles, tractors, diesel engines and other products. With so many advantages, the product has high commercial value.
Product Information
The following is the section for presenting details of the 25 amp dc to dc charger.
| Name | 24V DC TO DC 12V battery charger Flooded Gel AGM Lithium lifepo4 on board DC battery charger |
| Model | 241260BTOB |
| Main Battery voltage | 12V |
| Main battery type | GEL,Sealed,Flooded/AGM,Lifepo4,Lithium-ion(NCM) |
| Starter battery voltage | 24V |
| Starter battery type | Lead acid |
| DC-DC Max charging power | 780W |
| Main battery Max charging current | 60A |
| Self-consumption current | 24ma |
| Dimension | 215X194X70mm |
| Weight | 1.8kg |
| Accessories(Optional) | Monitor(MT2) |
| Bluetooth Dongle(BT10) | |
| Temperature Sensor(TRS) |
B2B Charge
It means to charge the main battery through alternator and starter battery. If it is not used in the vehicle, you can also use one battery to charge another battery
1. When the vehicle is running, the vehicle alternator can quickly charge the main battery through the charger at full power
2. The charger can charge the main battery according to the specified voltage and current by boosting or stepping down to ensure that the main battery is in accordance with the standard.
24V DC TO DC 12V battery charger Flooded Gel AGM Lithium lifepo4 on board DC
battery charger
Other Functions
1. Fully automatic charging: In order to continuously charge the battery, the controller can always be connected to the car battery. When the charging energy is stopped, such as the car stops driving, the battery will not discharge in the reverse direction.
2. Multiple protection functions: with overheating, overvoltage, short circuit, wrong connection protection
3. External temperature sensor: The ambient temperature will affect the parameters for charging the battery. The controller needs to perform parameter compensation according to the temperature of the battery, especially in places with large temperature changes. It is strongly recommended to install a temperature sensor.
Note: Lithium batteries do not require temperature compensation
4. Lithium battery automatic wake-up function: When the lithium battery BMS is protected for some reason, the controller can automatically wake up the BMS and continue to charge the lithium battery
24V DC TO DC 12V battery charger Flooded Gel AGM Lithium lifepo4 on board DC
battery charger
Battery life and efficiency
1 Ensure that the battery installation environment is ventilated and dissipated. The LiFePO4 battery is recommended to work in an environment above 0 degrees Celsius, otherwise the battery characteristics will drop a lot
2. The battery must be fully charged and stored, and it must be charged regularly to ensure that it is not stored under power, otherwise it will affect the battery life
3. Lead-acid batteries that are completely empty must be charged as soon as possible, otherwise it may cause permanent damage!
4. The lithium battery must have a BMS (Battery Management System). Try to avoid completely emptying the battery.
Product Introduction
Company Advantages
Located in shen zhen, Shenzhen Skyfavor Technology Co., ltd, a company, specializes in the business of Battery charger. With the enterprise spirit, Skyfavor intends to be honest, dedicated and innovative. Based on honesty, we seek common development with partners. With the main focus on brand building, we keep pace with the times and constantly improve ourselves under the guidance of market demand. Our goal is to become a leading enterprise in the industry. Skyfavor has a group of high-quality and high-efficiency technical talents. They have rich industry experience and exquisite production technology. They provide strong support for efficient business operation. With professional engineers and technicians in our company, Skyfavor is able to provide one-stop and comprehensive solutions for customers.
Welcome everyone to come for consultation.
